Lukies Flanges, based right here in Kinshasa, is your trusted partner for robust industrial connections across Congo. We specialize in the reliable supply and manufacturing of EN 1092-1 Type 05 flanges, a cornerstone component for demanding piping systems. Our focus is on delivering high-quality, locally available solutions that meet the rigorous standards required by the region’s growing industrial and energy sectors, ensuring your projects benefit from both superior products and dependable local support.
These Type 05 flanges, often called blank flanges, are typically crafted from durable carbon or stainless steel. Their composition is carefully controlled to ensure excellent strength and corrosion resistance. The mechanical properties are defined by the EN 1092-1 standard, guaranteeing they can withstand significant pressure and temperature loads, making them a fundamentally strong and reliable sealing solution for closing off pipe ends or vessels securely.
Lukies Flanges, a leading supplier in Kinshasa, Congo, offers an extensive selection of EN 1092-1 Type 05 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Pressure | PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160 |
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| DN | D i a m e t e r | Bolts | Thickness | Tollerance | Surface | Surface | Net | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| outside | bolt | bolt | Nr | Type | allowed on | for gasket | weight | ||||
| circle | holes | thickness | thigtness | ||||||||
| D | K | L | C1 | +/ – mm | d1 | f1 | Gmax | kg | |||
| 15 | 95 | 65 | 14 | 4 | M12 | 16 | 1 | 45 | 2 | 0,67 | |
| 20 | 105 | 75 | 14 | 4 | M12 | 18 | 1 | 58 | 2 | 0,94 | |
| 25 | 115 | 85 | 14 | 4 | M12 | 18 | 1 | 68 | 2 | 1,11 | |
| 32 | 140 | 100 | 18 | 4 | M16 | 18 | 1 | 78 | 2 | 1,82 | |
| 40 | 150 | 110 | 18 | 4 | M16 | 18 | 1 | 88 | 3 | 2,08 | |
| 50 | 165 | 125 | 18 | 4 | M16 | 18 | 1 | 102 | 3 | 2,59 | |
| 65 | 185 | 145 | 18 | 4;8 | M16 | 18 | 1 | 122 | 3 | 55 | 3,32 |
| 80 | 200 | 160 | 18 | 8 | M16 | 20 | 1,5 | 138 | 3 | 70 | 3,60 |
| 100 | 220 | 180 | 18 | 8 | M16 | 20 | 1,5 | 158 | 3 | 90 | 4,39 |
| 125 | 250 | 210 | 18 | 8 | M16 | 22 | 1,5 | 188 | 3 | 115 | 5,41 |
| 150 | 285 | 240 | 22 | 8 | M20 | 22 | 1,5 | 212 | 3 | 140 | 7,14 |
| 200 | 340 | 295 | 22 | 12 | M20 | 24 | 1,5 | 268 | 3 | 190 | 9,73 |
| 250 | 405 | 355 | 26 | 12 | M24 | 26 | 1,5 | 320 | 3 | 235 | 14,21 |
| 300 | 460 | 410 | 26 | 12 | M24 | 28 | 1,5 | 378 | 4 | 285 | 18,99 |
| 350 | 520 | 470 | 26 | 16 | M24 | 30 | 1,5 | 438 | 4 | 330 | 28,13 |
| 400 | 580 | 525 | 30 | 16 | M27 | 32 | 1,5 | 490 | 4 | 380 | 35,86 |
| 450 | 640 | 585 | 30 | 20 | M27 | 40 | 1,5 | 550 | 4 | 425 | 46,13 |
| 500 | 715 | 650 | 33 | 20 | M30 | 44 | 1,5 | 610 | 4 | 475 | 64,03 |
| 600 | 840 | 770 | 36 | 20 | M33 | 54 | 2 | 725 | 5 | 575 | 96,05 |
| 700 | 910 | 840 | 36 | 24 | M33 | 58 | 2 | 795 | 5 | 670 | 80,64 |
| 800 | 1025 | 950 | 39 | 24 | M36 | 62 | 2 | 900 | 5 | 770 | 102,58 |
| 900 | 1125 | 1050 | 39 | 28 | M36 | 64 | 2 | 1000 | 5 | 860 | 117,57 |
| 1000 | 1255 | 1170 | 42 | 28 | M39 | 68 | 2 | 1115 | 5 | 960 | 149,58 |
| 1200 | 1485 | 1390 | 48 | 32 | M45 | * | 2 | 1330 | 5 | 1160 | |
| Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| k | D | b | d2 | Thread | Bolt holes | KG | |
| 15 | 65 | 95 | 16 | 14 | M12 | 4 | 0,813 |
| 20 | 75 | 105 | 18 | 14 | M12 | 4 | 1,140 |
| 25 | 85 | 115 | 18 | 14 | M12 | 4 | 1,380 |
| 32 | 100 | 140 | 18 | 18 | M16 | 4 | 2,030 |
| 40 | 110 | 150 | 18 | 18 | M16 | 4 | 2,350 |
| 50 | 125 | 165 | 18 | 18 | M16 | 4 | 2,880 |
| 65 | 145 | 185 | 18 | 18 | M16 | 4 | 3,643 |
| 80 | 160 | 200 | 20 | 18 | M16 | 8 | 4,610 |
| 100 | 180 | 220 | 20 | 18 | M16 | 8 | 5,650 |
| 125 | 210 | 250 | 22 | 18 | M16 | 8 | 8,130 |
| 150 | 240 | 285 | 22 | 22 | M20 | 8 | 10,500 |
| 200 | 295 | 340 | 24 | 22 | M20 | 12 | 16,200 |
| 250 | 355 | 405 | 26 | 26 | M24 | 12 | 25,000 |
| 300 | 410 | 460 | 28 | 26 | M24 | 12 | 35,100 |
| 350 | 470 | 520 | 30 | 26 | M24 | 16 | 48,000 |
| 400 | 525 | 580 | 32 | 30 | M27 | 16 | 63,500 |
| 450 | 585 | 640 | 40 | 30 | M27 | 20 | 96,600 |
| 500 | 650 | 715 | 44 | 33 | M30 | 20 | 133,000 |
| 600 | 770 | 840 | 54 | 36 | M33 | 20 | 226,000 |
| 700 | 840 | 910 | 58 | 36 | M33 | 24 | 285,000 |
| 800 | 950 | 1025 | 62 | 39 | M36 | 24 | 388,000 |
| 900 | 1050 | 1125 | 64 | 39 | M36 | 28 | 483,000 |
| 1000 | 1170 | 1255 | 68 | 42 | M39 | 28 | 640,000 |
EN 1092-1 Type 05 flanges are widely used in various industries for joining pipes, valves, and other equipment in high-pressure and high-temperature systems. Common applications include the oil and gas, petrochemical, chemical, and water treatment sectors, where reliable and leak-free connections are essential. These flanges are ideal for use in pipeline systems, pumps, heat exchangers, and pressure vessels. Their compatibility with European standards ensures they are trusted for safety-critical operations, providing durability and long-lasting performance in both industrial and marine environments.
Yes, we offer custom sizes for EN 1092-1 Type 05 Flanges to meet specific project needs. Our team at Lukies Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@lukiesflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
