DIN 2633 PN16 Weld Neck Flanges Manufacturer and Supplier In Kinshasa, Congo

Nestled in the heart of Kinshasa, Lukies Flanges stands as a cornerstone for industry, providing critical components that keep the lifeblood of modern infrastructure flowing. We take particular pride in our DIN 2633 PN16 Weld Neck Flanges, which are engineered as the gold standard for creating secure, high-pressure connections in demanding environments. When you source from us, you’re not just buying a product; you’re investing in the reliability that powers progress across Congo and beyond.

DIN 2633 PN16 Standards Weld Neck Flanges in Kinshasa, DIN 2633 PN16 Weld Neck Plate Flange in Lubumbashi, Raised Face DIN 2633 PN16 WNRF Flanges in Bukavu , Stainless Steel DIN 2633 PN16 Weld Neck Flanges in Mbuji-Mayi, DIN 2633 PN16 Welding Neck Pipe Flange in Kisangani, Best Price of DIN 2633 PN16 Weld Neck Flange Manufacturer in Congo.

Stainless Steel DIN 2633 PN16 Weld Neck Flanges

Alloy Steel DIN 2633 PN16 Weld Neck Flanges

Alloy 20 DIN 2633 PN16 Weld Neck Flanges

Crafted from superior materials, these weld neck flanges are designed for endurance. Their composition is specifically tailored to meet the rigorous requirements of the DIN 2633 standard, ensuring consistent performance under a pressure rating of 16 bar. This translates to a product with excellent mechanical strength and a proven ability to withstand significant stress and temperature fluctuations, providing a dependable, long-lasting seal for your critical piping systems.

Monel DIN 2633 PN16 WNRF Flange in Congo, Hastelloy DIN 2633 PN16 Weld Neck Flanges in Kinshasa, Titanium DIN 2633 PN16 Welding Neck Flanges in Kisangani, SS DIN 2633 PN16 Weld Neck Flanges Stockist in Lubumbashi, Nickel Alloy DIN 2633 PN16 Weld Neck Flanges in Bukavu , Inconel DIN 2633 PN16 WNRF Flanges in Mbuji-Mayi, Alloy Steel DIN 2633 PN16 Weld Neck Flanges, Duplex Steel DIN 2631 Weld Neck Flange, Carbon Steel DIN 2633 PN16 Welding Neck Flanges in Congo.

DIN 2633 PN16 Weld Neck Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2633 PN16 Weld Neck Flanges Dimensions

Germany standard flange DIN 2633 welding neck flanges; nominal pressure 16
Brides à souder à collerette DIN 2633: pression nominale 16
Pipe			Flange				Neck				Raised face		Screws			Weight
																(7,85 Kg/dm3)
Rated	d1		D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
Diameter	ISO Series	DIN Series
15	–	20	95	14	65	35	30	2	4	6	45	2	4	M 12	14	0,648
	21,3	–					32
20	–	25	105	16	75	38	38	2,3	4	6	58	2	4	M 12	14	0,952
	26,9	–					40
25	–	30	115	16	85	38	42	2,6	4	6	68	2	4	M 12	14	1,14
	33,7	–					45
32	–	38	140	16	100	40	52	2,6	6	6	78	2	4	M 16	18	1,69
	42,4	–					56
40	–	44,5	150	16	110	42	60	2,6	6	7	88	3	4	M 16	18	1,86
	48,3	–					64
50	–	57	165	18	125	45	72	2,9	6	8	102	3	4	M 16	18	2,53
	60,3	–					75
65	76,1	–	185	18	145	45	90	2,9	6	10	122	3	4	M 16	18	3,06
80	88,9	–	200	20	160	50	105	3,2	8	10	138	3	8	M 16	18	3,7
100	–	108	220	20	180	52	125	3,6	8	12	158	3	8	M 16	18	4,62
	114,3	–					131
125	–	133	250	22	210	55	150	4	8	12	188	3	8	M 16	18	6,3
	139,7	–					156
150	–	159	285	22	240	55	175	4,5	10	12	212	3	8	M 20	22	7,75
	168,3	–					184
(175)	193,7	–	315	24	270	60	210	5,4	10	12	242	3	8	M 20	22	9,85
200	219,1	–	340	24	295	62	235	5,9	10	16	268	3	12	M 20	22	11
250	–	267	405	26	355	70	285	6,3	12	16	320	3	12	M 24	26	15,6
	273	–					292
300	323,9	–	460	28	410	78	344	7,1	12	16	378	4	12	M 24	26	22
350	355,6	–	520	30	470	82	390	8	12	16	438	4	16	M 24	26	31,2
	–	368														28,8
400	406,4	–	580	32	525	85	445	8	12	16	490	4	16	M 27	30	39,3
	–	419														36,3
(450)	457	–	640	34	585	85	490	8	12	16	550	4	20	M 27	30	44,3
500	508	–	715	34	650	90	548	8	12	16	610	4	20	M 30	33	61
600	610	–	840	36	770	95	652	8,8	12	18	725	5	20	M 33	36	75,4
700	711	–	910	36	840	100	755	8,8	12	18	795	5	24	M 33	36	77
800	813	–	1025	38	950	105	855	10	12	20	900	5	24	M 36	39	101
900	914	–	1125	40	1050	110	955	10	12	20	1000	5	28	M 36	39	122
1000	1016	–	1255	42	1170	120	1058	10	16	22	1115	5	28	M 39	42	162

Largest DIN 2633 PN16 Weld Neck Flanges Supplier in Kinshasa, Congo

Lukies Flanges, a leading supplier in Kinshasa, Congo, offers an extensive selection of DIN 2633 PN16 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

DIN 2633 PN16 Weld Neck Flanges are used in medium-pressure piping systems across industries such as oil and gas, petrochemical, water treatment, and power generation. Their robust design ensures secure, leak-proof connections between pipes, valves, and equipment, making them ideal for systems exposed to fluctuating temperatures and pressures. Commonly installed in critical applications, these flanges provide reliable performance and stability in process pipelines, pumps, and compressors. Their durability and precise alignment make them essential for maintaining system integrity and optimizing operational efficiency in high-demand environments.

DIN 2633 PN16 Welding Neck Flanges Stockist in Kisangani, DIN 2633 PN16 Weld Neck Flanges Supplier in Lubumbashi, DIN 2633 PN16 Weld Neck Flanges Supplier in Kinshasa, DIN 2633 PN16 Welding Neck Flanges Stockist in Congo, DIN 2633 PN16 Weld Neck Flanges Manufacturer in MM, DIN 2633 PN16 WNRF Flanges Manufacturer in Congo.

Types of DIN 2633 PN16 Weld Neck Flanges

Are Custom Sizes Available for DIN 2633 PN16 Weld Neck Flanges?

Yes, we offer custom sizes for DIN 2633 PN16 Weld Neck Flanges to meet specific project needs. Our team at Lukies Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@lukiesflanges.com.

DIN 2633 PN16 Weld Neck Flanges Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2633 PN16 Weld Neck Flanges in Congo.

DIN 2633 PN16 Weld Neck Flange Dimensions	Raised Face DIN 2633 PN16 Weld Neck Flange Manufacturer
DIN 2633 PN16 Weld Neck Flange Manufacturer	Flat Face DIN 2633 PN16 Weld Neck Flange Manufacturer
30 inch DIN 2633 PN16 Weld Neck Flange Dealer	Raised Face DIN 2633 PN16 Weld Neck Flanges Manufacturer
DIN 2633 PN16 Weld Neck Pipe Flanges Wholesaler	DIN 2633 PN16 WNRF Flanges Supplier
DIN 2633 PN16 WNRF Flange Stockist in Congo	Raised Faced DIN 2633 PN16 Slip-On flanges Dealer in Congo
Raised Face DIN 2633 PN16 Weld Neck Plate Flanges	Titanium DIN 2633 PN16 Welding Neck Flanges
18 inch DIN 2633 PN16 Carbon Steel Weld Neck Flange	DIN 2633 PN16 Weld Neck Flange Dimensions in mm
DIN 2633 PN16 WNRF Flanges Supplier in Kinshasa	Alloy Steel DIN 2633 PN16 Weld Neck Flanges Manufacturer in Congo
Nickel Alloy DIN 2633 PN16 Welding Neck Flange	Mild Steel DIN 2633 PN16 Weld Neck Flange
Alloy Steel DIN 2633 PN16 Welding Neck Flanges	Copper Nickel DIN 2633 PN16 Weld Neck Flanges at Best Price
DIN 2633 PN16 Welding Neck FF Flange Supplier	Suppliers of DIN 2633 PN16 Weld Neck Flange
DIN 2633 PN16 WNRF Flanges Distributor in Kisangani	Flat Face DIN 2633 PN16 Weld Neck Flanges Exporter
DIN 2633 PN16 Welding Neck Flanges Supplier in Lubumbashi	MS DIN 2633 PN16 Weld Neck Flange
DIN 2633 PN16 Large Diameter Weld Neck Flange	30 Inch DIN 2633 PN16 Weld Neck Pipe Flange Dimensions
8 Inch DIN 2633 PN16 Welding Neck Pipe Flanges	DIN 2633 PN16 Weld Neck Flanges Stockist
Carbon Steel Raised Face DIN 2633 PN16 Weld Neck Flange Stockist	Duplex Steel DIN 2633 PN16 WNRF Flanges Supplier in Kinshasa
ASME SA105N Raised Faced DIN 2633 PN16 Weld Neck Flanges	18 inch Carbon Steel DIN 2633 PN16 Weld Neck Flange
Carbon Steel DIN 2633 PN16 Welding Neck Flange	DIN 2633 PN16 Weld Neck RF Flange Supplier
DIN 2633 PN16 Weld Neck Pipe Flanges Supplier in Bukavu	Duplex Steel DIN 2633 PN16 Weld Neck Flanges
4 inch Stainless Steel DIN 2633 PN16 Weld Neck Flange	DIN 2633 PN16 Weld Neck RF Flanges Stockholder
Stainless Steel DIN 2633 PN16 Weld Neck Flange	ASTM B564 Raised Faced DIN 2633 PN16 Weld Neck Flanges
DIN 2633 PN16 WNRF Flange Exporter	DIN 2633 PN16 Weld Neck Flange Pressure Ratings
German Standard DIN 2633 PN16 Weld Neck Flanges	DIN 2633 PN16 Weld Neck Flange Supplier in Congo

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.

Raise Face DIN 2633 PN16 Weld Neck Flanges Manufacturer in Kinshasa, PED Certified DIN 2633 PN16 WNRF Pipe Flanges Manufacturer in Kisangani, DIN 2633 PN16 Weld Neck Flanges Stockholder in Lubumbashi, Flat Face DIN 2633 PN16 Weld Neck Flanges in Bukavu , DIN 2633 PN16 Welding Neck Flanges Pressure Rating in Mbuji-Mayi, DIN 2633 PN16 WNRF Flanges Dealer in Congo.

Application Industry of DIN 2633 PN16 Weld Neck Flanges

Oil and gas industry
Transporting materials
Pulp and paper industry
Power plants
Energy industries
Modern architecture
Fluid piping
Dairy and food processing
Heat exchanger
Textile machinery
Water waste projects
Synthetic fiber
Exhaust gas and Exhaust air
Construction
Automotive industry
