DIN 2635 PN40 Weld Neck Flanges Manufacturer and Supplier In Kinshasa, Congo

Operating from the heart of Kinshasa, Lukies Flanges is your trusted local partner for robust industrial solutions. We specialize in the manufacturing and supply of high-performance DIN 2635 PN40 weld neck flanges, engineered to meet the demanding needs of Congo’s growing industrial sector. Our commitment is to deliver not just a product, but reliability and peace of mind, ensuring your piping systems are built on a foundation of local expertise and uncompromising quality.

DIN 2635 PN40 Standards Weld Neck Flanges in Kinshasa, DIN 2635 PN40 Weld Neck Plate Flange in Lubumbashi, Raised Face DIN 2635 PN40 WNRF Flanges in Bukavu , Stainless Steel DIN 2635 PN40 Weld Neck Flanges in Mbuji-Mayi, DIN 2635 PN40 Welding Neck Pipe Flange in Kisangani, Best Price of DIN 2635 PN40 Weld Neck Flange Manufacturer in Congo.

Stainless Steel DIN 2635 PN40 Weld Neck Flanges

Alloy Steel DIN 2635 PN40 Weld Neck Flanges

Alloy 20 DIN 2635 PN40 Weld Neck Flanges

These flanges are typically forged from high-grade carbon or stainless steel, giving them exceptional strength and durability. They are designed to withstand a pressure rating of 40 bar, making them suitable for high-pressure systems. The long, tapered hub provides a vital reinforcement at the joint, ensuring a smooth flow transition and reducing stress concentrations for a secure, long-lasting connection in critical applications.

Monel DIN 2635 PN40 WNRF Flange in Congo, Hastelloy DIN 2635 PN40 Weld Neck Flanges in Kinshasa, Titanium DIN 2635 PN40 Welding Neck Flanges in Kisangani, SS DIN 2635 PN40 Weld Neck Flanges Stockist in Lubumbashi, Nickel Alloy DIN 2635 PN40 Weld Neck Flanges in Bukavu , Inconel DIN 2635 PN40 WNRF Flanges in Mbuji-Mayi, Alloy Steel DIN 2635 PN40 Weld Neck Flanges, Duplex Steel DIN 2631 Weld Neck Flange, Carbon Steel DIN 2635 PN40 Welding Neck Flanges in Congo.

DIN 2635 PN40 Weld Neck Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2635 PN40 Weld Neck Flanges Dimensions

Pipe			Flange				Neck				Raised face		Screws			Weight
Pipe			Flange				Neck				Raised face		Screws			(7,85 Kg/dm3)
Rated	d1		D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
Diameter	ISO Series	DIN Series	D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
15	–	20	95	16	65	38	30	2	4	6	45	2	4	M 12	14	0,746
15	21,3	–	95	16	65	38	32	2	4	6	45	2	4	M 12	14	0,746
20	–	25	105	18	75	40	38	2,3	4	6	58	2	4	M 12	14	1,06
20	26,9	–	105	18	75	40	40	2,3	4	6	58	2	4	M 12	14	1,06
25	–	30	115	18	85	40	42	2,6	4	6	68	2	4	M 12	14	1,29
25	33,7	–	115	18	85	40	45	2,6	4	6	68	2	4	M 12	14	1,29
32	–	38	140	18	100	42	52	2,6	6	6	78	2	4	M 16	18	1,88
32	42,4	–	140	18	100	42	56	2,6	6	6	78	2	4	M 16	18	1,88
40	–	44,5	150	18	110	45	60	2,6	6	7	88	3	4	M 16	18	2,33
40	48,3	–	150	18	110	45	64	2,6	6	7	88	3	4	M 16	18	2,33
50	–	57	165	20	125	48	72	2,9	6	8	102	3	4	M 16	18	2,82
50	60,3	–	165	20	125	48	75	2,9	6	8	102	3	4	M 16	18	2,82
65	76,1	–	185	22	145	52	90	2,9	6	10	122	3	8	M 16	18	3,74
80	88,9	–	200	24	160	58	105	3,2	8	12	138	3	8	M 16	18	4,75
100	–	108	235	24	190	65	128	3,6	8	12	162	3	8	M 20	22	6,52
100	114,3	–	235	24	190	65	134	3,6	8	12	162	3	8	M 20	22	6,52
125	–	133	270	26	220	68	155	4	8	12	188	3	8	M 24	26	9,07
125	139,7	–	270	26	220	68	162	4	8	12	188	3	8	M 24	26	9,07
150	–	159	300	28	250	75	182	4,5	10	12	218	3	8	M 24	26	11,8
150	168,3	–	300	28	250	75	192	4,5	10	12	218	3	8	M 24	26	11,8
(175)	193,7	–	350	32	295	82	218	5,6	10	15	260	3	12	M 27	30	18,2
200	219,1	–	375	34	320	88	244	6,3	10	16	285	3	12	M 27	30	21,5
250	–	267	450	38	385	105	298	7,1	12	18	345	3	12	M 30	33	34,9
250	273	–	450	38	385	105	306	7,1	12	18	345	3	12	M 30	33	34,9
300	323,9	–	515	42	450	115	362	8	12	18	410	4	16	M 30	33	49,7
350	355,6	–	580	46	510	125	408	8,8	12	20	465	4	16	M 33	36	68,1
350	–	368	580	46	510	125	408	8,8	12	20	465	4	16	M 33	36	68,1
400	406,4	–	660	50	585	135	462	11	12	20	535	4	16	M 36	39	96,5
400	–	419	660	50	585	135	462	11	12	20	535	4	16	M 36	39	96,5
(450)	457	–	685	50	610	135	500	12,5	12	20	560	4	20	M 36	39	99,7
500	508	–	755	52	670	140	562	14,2	12	20	615	4	20	M 39	42	117

Largest DIN 2635 PN40 Weld Neck Flanges Supplier in Kinshasa, Congo

Lukies Flanges, a leading supplier in Kinshasa, Congo, offers an extensive selection of DIN 2635 PN40 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

DIN 2635 PN40 Weld Neck Flanges are primarily used in high-pressure piping systems across industries such as oil and gas, petrochemical, power generation, and chemical processing. Their robust design ensures secure, leak-proof connections between pipes, valves, and other equipment in demanding environments exposed to high pressure, temperature, and fluctuating conditions. These flanges are commonly installed in critical systems like pipelines, reactors, compressors, and pumps, where performance and reliability are paramount. Their durability and precision make them essential for maintaining system integrity and long-term operational efficiency.

DIN 2635 PN40 Welding Neck Flanges Stockist in Kisangani, DIN 2635 PN40 Weld Neck Flanges Supplier in Lubumbashi, DIN 2635 PN40 Weld Neck Flanges Supplier in Kinshasa, DIN 2635 PN40 Welding Neck Flanges Stockist in Congo, DIN 2635 PN40 Weld Neck Flanges Manufacturer in MM, DIN 2635 PN40 WNRF Flanges Manufacturer in Congo.

Types of DIN 2635 PN40 Weld Neck Flanges

Are Custom Sizes Available for DIN 2635 PN40 Weld Neck Flanges?

Yes, we offer custom sizes for DIN 2635 PN40 Weld Neck Flanges to meet specific project needs. Our team at Lukies Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@lukiesflanges.com.

DIN 2635 PN40 Weld Neck Flanges Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2635 PN40 Weld Neck Flanges in Congo.

DIN 2635 PN40 WNRF Flanges Supplier in Kinshasa	Alloy Steel DIN 2635 PN40 Weld Neck Flanges Manufacturer in Congo
Nickel Alloy DIN 2635 PN40 Welding Neck Flange	Mild Steel DIN 2635 PN40 Weld Neck Flange
30 inch DIN 2635 PN40 Weld Neck Flange Dealer	Raised Face DIN 2635 PN40 Weld Neck Flanges Manufacturer
ASME SA105N Raised Faced DIN 2635 PN40 Weld Neck Flanges	18 inch Carbon Steel DIN 2635 PN40 Weld Neck Flange
18 inch DIN 2635 PN40 Carbon Steel Weld Neck Flange	DIN 2635 PN40 Weld Neck Flange Dimensions in mm
Alloy Steel DIN 2635 PN40 Welding Neck Flanges	Copper Nickel DIN 2635 PN40 Weld Neck Flanges at Best Price
DIN 2635 PN40 Welding Neck FF Flange Supplier	Suppliers of DIN 2635 PN40 Weld Neck Flange
DIN 2635 PN40 WNRF Flanges Distributor in Kisangani	Flat Face DIN 2635 PN40 Weld Neck Flanges Exporter
Carbon Steel DIN 2635 PN40 Welding Neck Flange	DIN 2635 PN40 Weld Neck RF Flange Supplier
Raised Face DIN 2635 PN40 Weld Neck Plate Flanges	Titanium DIN 2635 PN40 Welding Neck Flanges
DIN 2635 PN40 WNRF Flange Stockist in Congo	Raised Faced DIN 2635 PN40 Slip-On flanges Dealer in Congo
4 inch Stainless Steel DIN 2635 PN40 Weld Neck Flange	DIN 2635 PN40 Weld Neck RF Flanges Stockholder
DIN 2635 PN40 Welding Neck Flanges Supplier in Lubumbashi	MS DIN 2635 PN40 Weld Neck Flange
DIN 2635 PN40 Large Diameter Weld Neck Flange	30 Inch DIN 2635 PN40 Weld Neck Pipe Flange Dimensions
DIN 2635 PN40 WNRF Flange Exporter	DIN 2635 PN40 Weld Neck Flange Pressure Ratings
Carbon Steel Raised Face DIN 2635 PN40 Weld Neck Flange Stockist	Duplex Steel DIN 2635 PN40 WNRF Flanges Supplier in mm
DIN 2635 PN40 Weld Neck Pipe Flanges Wholesaler	DIN 2635 PN40 WNRF Flanges Supplier
DIN 2635 PN40 Weld Neck Flange Manufacturer	Flat Face DIN 2635 PN40 Weld Neck Flange Manufacturer
Stainless Steel DIN 2635 PN40 Weld Neck Flange	ASTM B564 Raised Faced DIN 2635 PN40 Weld Neck Flanges
DIN 2635 PN40 Weld Neck Flange Dimensions	Raised Face DIN 2635 PN40 Weld Neck Flange Manufacturer
8 Inch DIN 2635 PN40 Welding Neck Pipe Flanges	DIN 2635 PN40 Weld Neck Flanges Stockist
DIN 2635 PN40 Weld Neck Pipe Flanges Supplier in Bukavu	Duplex Steel DIN 2635 PN40 Weld Neck Flanges
German Standard DIN 2635 PN40 Weld Neck Flanges	DIN 2635 PN40 Weld Neck Flange Supplier in Congo

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.

Raise Face DIN 2635 PN40 Weld Neck Flanges Manufacturer in Kinshasa, PED Certified DIN 2635 PN40 WNRF Pipe Flanges Manufacturer in Kisangani, DIN 2635 PN40 Weld Neck Flanges Stockholder in Lubumbashi, Flat Face DIN 2635 PN40 Weld Neck Flanges in Bukavu , DIN 2635 PN40 Welding Neck Flanges Pressure Rating in Mbuji-Mayi, DIN 2635 PN40 WNRF Flanges Dealer in Congo.

Application Industry of DIN 2635 PN40 Weld Neck Flanges

Oil and gas industry
Transporting materials
Pulp and paper industry
Power plants
Energy industries
Modern architecture
Fluid piping
Dairy and food processing
Heat exchanger
Textile machinery
Water waste projects
Synthetic fiber
Exhaust gas and Exhaust air
Construction
Automotive industry
